NZ Cabins Made from high-strength aircraft-grade aluminum alloy teambuy
NZ Cabins Made from high-strength aircraft-grade aluminum alloy teambuy
Hurry up, only 1 item left in stock.
Logistics: After the order is successfully shipped from China, it is expected to take 2 months to pick up the goods at the designated warehouse at Auckland Airport, by mail.
Tax:Includes GST, but requires separate customs declaration, you need to prepare the company and customs code for customs declaration in advance (individuals also need to apply)
Installation: We provide DIY installation videos, please prepare the specified tools and invite at least one person to help install. If you do not have the conditions, you can contact us to send the installation team, or ask professional installation workers to install.
Warranty: The design life of the product is 30 years, and we provide free replacement parts service for non-human damage within one year.
Product Specifications.
3.66/4.66/5.66/6.66x3.6x2.75m
Applicable Places:
Ground -level gardens, rooftop gardens, courtyards, etc.
Applicable Working Conditions:
All - terrain
Main Structure:
Prefabricated finished components, prefabricated structure
Basic Version:
Solid roof + glass on four sides
nterior Electrical Circuits:
Integrated ceiling light with a remote - controlled fan, 2 floor sock-
Connection Methods:
Bolt connection + nail connection
Glass Enclosure:
Fixed windows with a 60X60mm aluminum tube main frame.55 -series ordinary gray broken - bridge aluminum casementdoors and windows. All doors and windows are made of 5+9+5mmtempered Low -e glass.
Design Lifespan:
30+ years
Wind and Earthquake Resistance Level:
Grade 12+
Structural Fire Resistance:
Class A1/Fire Resistance of Plate Shel: Class B1 /Overall
Waterproof Grade: 6
Thermal Conductivity of the Roof and Wall:
0.030W/m.K
Detailed Configuration
Base Frame:60X60mm aluminum tube base frame (foundation
feet)
Chassis:120X60mm aluminum tube skeleton, 3mm - thick innel
and outer resin fiber mold plates, automotive paint finish,
18mm-thick OSB3 foor structure board, high -speed rail floor
rubber inside, 1000mm -wide component module
Ceiling:120X60mm aluminum tube skeleton, 3mm - thick inner
and outer resin fiber mold plates, automotive paint finish,fully - filled extruded polystyrene board for heat preservation.
1000mm -wide component module
Corner Column: 470X120X60X2160mm, aluminum plate C - type
folded part, profiled structure, 3mm - thick inner and outer resin
fiber mold plates, automotive paint finish
Solid Wall: 126mm thick.60X60mm aluminum tube structure.
inner and outer resin fiber mold plates, automotive paint finish, fully-filled extruded polystyrene board for heat preservation
